2L Jacketed Glass Reactor

High borosilicate glass reactor vessels with bottom valve;Glass dome with ports for inlet, solid feed, vacuum, etc;PTFE coated stirrer, mechanical seal;Adjustable speed stirrer drive;CE and ISO certificate.
  • ModelLGR-2L
  • BrandLABOAO
  • PortAny port in China
  • PackagePlywood case package
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat

Download

DESCRIPTION

Jacketed Reaction vessels are used for synthetic reaction of different types of materials in a controlled temperature and vacuum environment. Reaction Vessels can be used as an all in one tool for extraction, refinement, distillation, and hemoginization.Consisting of an inner vessel with either one or two jackets, a reactor uses temperature differentials created by a chiller to change it's internal environment. Reaction vessels also operate under vacuum making them ideal for any atmospheric sensitive applications. They can be made out of glass and range in volume from 1L to 200L.


FEATURES

1. A full set of glassware with GG3.3 borosilicate glass that is heat/cold/corrosion-resistant.

2. Wide range of temperature operations, from -60°C to 250°C.

3. Solvent-resistant PTFE seal ensure long time durability and operation, sealing is -0.098Mpa.

4. The PT100 temperature, and is a liquid crystal display. More accurate temperature measurement and more convenient.

5. Frequency control, AC induction motor. Constant speed, brushless, no spark, security and stability, and continuous work.

6. Heavy duty stainless steel supporting framework with lockable casters for mobility and stability. (whole support and glass vessel shipped pre-assembled)

7. Rugged stainless steel reinforced PTFE stirrer with anchored agitator, suitable for a wide range of viscous materials. multi-layer stirring blades is optional.

8. The bottom flange discharge port with a Teflon value, aluminum parts flange fixed.

SPECIFICATIONS

Model

LGR-2L

Kettle volume

2L inner   diameter 120mm,outer diameter 150mm,inner length 230mm

Jacketed volume

about 250ml

Voltage/frequency

220V/50HZ

Stirring power

40W

Stirring speed

0-1100r/min

Temperature range vessel can bear

-80 to 250

Temperature accuracy

±1

Vacuum degree

0.098Mpa

Cover diameter

Φ150mm

5port of the cover

Stirring port

Φ50mm flange port

Condenser port

24# standard port

Constant pressure funnel port

24# standard port

Relief port

19# standard port

Temperature measure port

19# standard port

Stirring  paddle

Φ10*500H(mm), leafing 90mm

Condenser size

Φ40*350H(mm), upper with 24# standard port, down with   24#  standard plug

Constant pressure funnel

250ml,  upper with 24#   standard port matched with glass plug, down with 24# standard plug

Relief valve

19# standard plug valve, vent nozzlepadoga connector),outer diameter 10mm

Temperature measuring port

19# standard plug, glass temperature measuing port

In and out circulation port of the sandwich

Φ35 flange port matched with ring flange, adapter pagoda   connector ,outer diameter 15mm

Baiting port

Screw port matched with PTFE baiting valve, Φ18mm baiting   port, inclined discharging nozzle (pagoda connector), Φ12mm,from floor 350mm

Vacuum suction nozzle

24# glass exhaustorsuction nozzle(padoga connector),outer diameter 10mm

In and out circulation nozzle of condenser coil

padoga connector,outer diameter 10mm

Overall dimension (W*L*H)

330*350*1300mm

Net weight

18.5kg

Packing dimension

1200*400*450mm, 0.22m³

Packing weight

32.5kg
