200L Jacketed Glass Reactor

High borosilicate glass reactor vessels with bottom valve Glass dome with ports for inlet, solid feed, vacuum, etc. PTFE coated stirrer, mechanical seal Adjustable speed stirrer drive CE and ISO certificate.
  • ModelLGR-200L
  • BrandLABOAO
  • StockIn Stock
  • CustomizedOEM/ODM
  • CertificationCE
  • Min. Order1 unit
  • PortAny port in China
  • PackagePlywood case package
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat

Download

VIDEO

8 Advantages Of LABOAO Jacketed Glass Reactor

200L Jacketed Glass Reactor detail - Low speed booster motor, adjust speed 0-280 rpm.
1. Low speed booster motor, adjust speed 0-280 rpm.
200L Jacketed Glass Reactor detail - High borosilicate double layer glass reaction, 3 layer PTFE stirring anchor.
2. High borosilicate double layer glass reaction, 3 layer PTFE stirring anchor.
200L Jacketed Glass Reactor detail - Total 6 ports, for motor, solid adding, temperature sensor, condenser, feeding tank, air release.
3. Total 6 ports, for motor, solid adding, temperature sensor, condenser, feeding tank, air release.
200L Jacketed Glass Reactor detail - Oil vacuum meter, anti-vibration during stirring.
4. Oil vacuum meter, anti-vibration during stirring.
200L Jacketed Glass Reactor detail - Speed controller, can adjust speed and display temperture.
5. Speed controller, can adjust speed and display temperture.
200L Jacketed Glass Reactor detail - 10L feeding tank, GG-17 high borosilicate glass.
6. 10L feeding tank, GG-17 high borosilicate glass.
200L Jacketed Glass Reactor detail - 10L receiving flask, GG-17 high borosilicate glass.
7. 10L receiving flask, GG-17 high borosilicate glass.
200L Jacketed Glass Reactor detail - Discharge valve, easy to discharge materials. PTFE parts for anti-corrosion.
8. Discharge valve, easy to discharge materials. PTFE parts for anti-corrosion.

DESCRIPTION

Jacketed Reaction vessels are used for synthetic reaction of different types of materials in a controlled temperature and vacuum environment. Reaction Vessels can be used as an all in one tool for extraction, refinement, distillation, and hemoginization.Consisting of an inner vessel with either one or two jackets, a reactor uses temperature differentials created by a chiller to change it's internal environment. Reaction vessels also operate under vacuum making them ideal for any atmospheric sensitive applications. They can be made out of glass and range in volume from 1L to 200L.


FEATURES

1. A full set of glassware with GG3.3 borosilicate glass that is heat/cold/corrosion-resistant.

2. Wide range of temperature operations, from -60°C to 250°C.

3. Solvent-resistant PTFE seal ensure long time durability and operation, sealing is -0.098Mpa.

4. The PT100 temperature, and is a liquid crystal display. More accurate temperature measurement and more convenient.

5. Frequency control, AC induction motor. Constant speed, brushless, no spark, security and stability, and continuous work.

6. Heavy duty stainless steel supporting framework with lockable casters for mobility and stability. (whole support and glass vessel shipped pre-assembled)

7. Rugged stainless steel reinforced PTFE stirrer with anchored agitator, suitable for a wide range of viscous materials. multi-layer stirring blades is optional.

8. The bottom flange discharge port with a Teflon value, aluminum parts flange fixed.

SPECIFICATIONS

Model

LGR-200L

Kettle volume

200L inner diameter 600mm, outer diameter 650mm,inner   length 840mm

Jacketed volume

about 40L

Voltage/frequency

220V/50HZ

Stirring power

750W  1/5

Stirring speed

0-280r/min

Temperature   range vessel can bear

-80 to 250

Temperature   accuracy

±1

Vacuum degree

0.098Mpa   Negative pressure

Cover diameter

Φ340mm

6ports of cover

Stirring port

Φ60mm flange   port

Condenser reflux   port

50# ball mill   port

Adding dropwise   elbow port

50# ball mill   port

Relief port

34# standard   port

Temperature   measure port

Φ45mm flange   port

Solid feeding   port

Φ80mm flange   portinner diameter Φ60mm matched with PTFE   cover

Stirring  paddle

Φ20*1300H(mm),   leafing 240mm

Condenser size

Φ160*600H(mm),   down with Φ60mm flange port

Condensation   area

0.95

Reflux elbow

upper with Φ60mm   flange portleft with 50# ball mill plugright with 24# standard port matched with functional   valve, down with 50# ball mill plug valve

Adding dropwise   bottle

5L,tubular,   upper with 29# standard port matched with vent valve *2, 34# standard port   matched with glass plug

Receiving bottle

10Lupper with 50# ball mill port24# standard port matched with vent valve*2, down with   glass baiting valve

Relief valve

34# standard   plug  valvevent nozzle (pogada connector), outer diameter 12mm

In and out   circulation port of the sandwich

Φ45mm flange   port matched with ring flange, 6 points outside the wire adapter

Baiting port

Φ100mm flangeΦ65mm baiting portinclined   discharged port (pagoda connector), Φ40mmfrom floor 300mm

Vacuum suction   nozzle

padoga   connector,outer diameter 12mm

In and out   circulation nozzle of condenser coil

padoga   connector,outer diameter 15mm

Overall   dimension (W*L*H)

1250*930*2800mm

Net weight

175kg

Packing   dimension

2200*790*875mm 1385*880*910mm, 2.63m³

Packing weight

271kg (159+112)
