150L Jacketed Glass Reactor 150L Jacketed Glass Reactor
150L Jacketed Glass Reactor 150L Jacketed Glass Reactor

150L Jacketed Glass Reactor

Jacketed glass reactor is with double glass design, the reaction kettle placed with reaction menstruum can do the mixing reaction, and the interlayer can be added with different cold and heat sources (frozen liquid, hot water or hot oil) to do loop heating or cooling reaction.
  • ModelLGR-150L
  • BrandLABOAO
  • StockIn Stock
  • CustomizedOEM/ODM
  • CertificationCE
  • Min. Order1 unit
  • PortAny port in China
  • PackagePlywood case package
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat



Jacketed Reaction vessels are used for synthetic reaction of different types of materials in a controlled temperature and vacuum environment. Reaction Vessels can be used as an all in one tool for extraction, refinement, distillation, and hemoginization.Consisting of an inner vessel with either one or two jackets, a reactor uses temperature differentials created by a chiller to change it's internal environment. Reaction vessels also operate under vacuum making them ideal for any atmospheric sensitive applications. They can be made out of glass and range in volume from 1L to 200L.


1.A full set of glassware with GG3.3 borosilicate glass that is heat/cold/corrosion-resistant.

2.Wide range of temperature operations, from -60°C to 250°C.

3.Solvent-resistant PTFE seal ensure long time durability and operation, sealing is -0.098Mpa.

4.The PT100 temperature, and is a liquid crystal display. More accurate temperature measurement and more convenient.

5.Frequency control, AC induction motor. Constant speed, brushless, no spark, security and stability, and continuous work.

6.Heavy duty stainless steel supporting framework with lockable casters for mobility and stability. (whole support and glass vessel shipped pre-assembled)

7. Rugged stainless steel reinforced PTFE stirrer with anchored agitator, suitable for a wide range of viscous materials. multi-layer stirring blades is optional.

8.The bottom flange discharge port with a Teflon value, aluminum parts flange fixed.




Kettle volume

150L innder diameter 550mm, outer diameter 600mm, inner length 786mm

Jacketed volume

about 35L



Stirring power

750W  1/5

Stirring speed


Temperature accuracy


Vacuum degree

0.098Mpa (Negative pressure)

Cover diameter


6ports of cover

Stirring port

Φ60mm flange port

Condenser reflux port

50# ball mill port

Adding dropwise elbow port

50# ball mill port

Relief port

34# standard port

Temperature measure port

Φ45mm flange port

Solid feeding port

Φ80mm flange portinner diameter Φ60mm matched with PTFE cover

Stirring  paddle

Φ20*1300H(mm), leafing 240mm

Condenser size

Φ160*600H(mm), down with Φ60mm   flange port

Condensation area


Reflux elbow

upper with Φ60mm flange portleft with 50# ball mill plugright with 24# standard port   matched with functional valve, down with 50# ball mill plug valve

Adding dropwise bottle

5L,tubular, upper with 29# standard   port matched with vent valve *2, 34# standard port matched with glass plug

Receiving bottle

10Lupper with 50# ball mill port24# standard port matched with   vent valve*2, down with glass baiting valve

Relief valve

34# standard plug  valvevent nozzle (pogada connector),   outer diameter 12mm

In and out circulation port of the   sandwich

Φ45mm flange port matched with   ring flange, 6 points outside the wire adapter

Baiting port

Φ100mm flangeΦ65mm baiting portinclined discharged port (pagoda   connector), Φ40mmfrom floor 300mm

Vacuum suction nozzle

padoga connector,outer diameter   12mm

In and out circulation nozzle of   condenser coil

padoga connector,outer diameter   15mm

Overall dimension (W*L*H)


Net weight


Packing dimension

2160*740*840mm,  1360*750*850mm, 2.21m³

Packing weight

271kg (159+112)


  1. Factory direct sales with competitive price.
  2. Premium quality with CE & ISO certification.
  3. Strong product OEM & ODM customization capability.
  4. Promise production & on-time delivery.
  5. Perfect after-sales service, free product accessories.
  6. 15 years of experience in R&D and production of jacketed glass reactor machine.
laboao certification


We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.

laboao factory


Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.

laboao packaging and shipping


Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe LABOAO, we grow together!

laboao customer cases


Authenticity GuaranteedWe assure you purchase our products are 100% certified products.
24*7Hours ServiceProvide 7*24 hours service telephone & support email to help you solve problems quickly.
Technical SupportProvide equipment installation, adjustment, operation training, etc.
1 Year WarrantyFree maintenance and accessories within warranty period(not caused by human factors).
