1L Jacketed Glass Reactor

High borosilicate glass reactor vessels with bottom valve;Glass dome with ports for inlet, solid feed, vacuum, etc;PTFE coated stirrer, mechanical seal;Adjustable speed stirrer drive;CE and ISO certificate.
  • ModelLGR-1L
  • BrandLABOAO
  • StockIn Stock
  • CustomizedOEM/ODM
  • CertificationCE
  • Min. Order1 unit
  • PortAny port in China
  • PackagePlywood case package
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat

Download

DESCRIPTION

Jacketed Reaction vessels are used for synthetic reaction of different types of materials in a controlled temperature and vacuum environment. Reaction Vessels can be used as an all in one tool for extraction, refinement, distillation, and hemoginization.Consisting of an inner vessel with either one or two jackets, a reactor uses temperature differentials created by a chiller to change it's internal environment. Reaction vessels also operate under vacuum making them ideal for any atmospheric sensitive applications. They can be made out of glass and range in volume from 1L to 200L.


FEATURES

1. A full set of glassware with GG3.3 borosilicate glass that is heat/cold/corrosion-resistant.

2. Wide range of temperature operations, from -60°C to 250°C.

3. Solvent-resistant PTFE seal ensure long time durability and operation, sealing is -0.098Mpa.

4. The PT100 temperature, and is a liquid crystal display. More accurate temperature measurement and more convenient.

5. Frequency control, AC induction motor. Constant speed, brushless, no spark, security and stability, and continuous work.

6. Heavy duty stainless steel supporting framework with lockable casters for mobility and stability. (whole support and glass vessel shipped pre-assembled)

7. Rugged stainless steel reinforced PTFE stirrer with anchored agitator, suitable for a wide range of viscous materials. multi-layer stirring blades is optional.

8. The bottom flange discharge port with a Teflon value, aluminum parts flange fixed.

SPECIFICATIONS

Model LGR-1L
Kettle   volume1L,   inner diameter 120mm, outer diameter 150mm, inner length 160mm
Jacketed volumeabout   200ml
Voltage/frequency220V/50HZ
Stirring power40W
Stirring speed0-1100r/min
Temperature range vessel can bear-80   to 250
Temperature accuracy±1℃
Vacuum degree0.098Mpa
Cover diameterΦ150mm
5port of the coverStirring   port Φ50mm   flange port
Condenser port24#   standard port
Constant pressure funnel port 24#   standard port
Relief port 19#   standard port
Temperature measure port 19#   standard port
Stirring  paddle Φ10*450H(mm),   leafing 80mm
Condenser size Φ40*350H(mm),  upper with 24# standard port, down with   24#  standard plug
Constant pressure funnel250ml,   upper with 24# standard port matched with glass plug, down with 24# standard   plug
Relief valve 19#   standard plug valve, vent nozzle(padoga connector),outer diameter 10mm
Temperature measuring port 19#   standard plug, glass temperature measuing port
In and out circulation port of the sandwichΦ35   flange port matched with ring flange, adapter pagoda connector ,outer   diameter 15mm
Baiting   port Screw   port matched with PTFE baiting valve, Φ18mm baiting port, inclined   discharging nozzle (pagoda connector), Φ12mm,from floor 350mm
Vacuum suction nozzle 24#   glass exhaustor,suction nozzle(padoga connector),outer diameter 10mm
In and out circulation nozzle of condenser coil padoga   connector,outer diameter 10mm
Overall   dimension (W*L*H)330*350*1220mm
Net weight 17.5kg
Packing dimension 1200*400*450mm,0.22m³
Packing weight 32.5kg
