Explosion-proof Lifting And Rotating Double Layer Glass Reactor

The stirring system of LGR-EX5S/ LGR-EX10S/ LGR-EX20S/ LGR-EX100S explosion-proof lifting rotating glass reactor adopts ceramic bearings and mechanical seals.
  • ModelLGR-EX5S/EX10S/EX20S/100S
  • BrandLABOAO
  • PortAny port in China
  • PackagePlywood case package
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat

Download

DESCRIPTION

1. This machine has an electric constant speed stirring system, a condensation dripping system, and the interlayer of the kettle body needs to be connected with external heating or cooling circulation equipment.

2. While stirring the materials, the heating bath heats the contents of the kettle, which can improve the evaporation efficiency under vacuum conditions.

3. When the solvent vapor passes through the glass condensing coil, it is cooled to liquid, which can be returned to the kettle or recovered through the recovery bottle.

4. The lifting and rotating reaction kettle is based on the ordinary reaction kettle, which can make the kettle cover and the part above the kettle cover rise as a whole. After the stirring rod leaves the kettle body, the kettle body can be rotated 150 degrees to the left by the handwheel, and poured out directly. Materials, easy to clean the kettle body.


FEATURES

1. The parts in contact with the material are all made of high borosilicate glass (expansion coefficient 3.3) and polytetrafluoroethylene material, which has stable performance and is not easy to chemically react with the material, and is easy to use.

2. The main bracket is made of square steel anti-corrosion spray + aluminum alloy + stainless steel, which is anti-corrosion, anti-oxidation, beautiful and durable.

3. The kettle cover is made of polytetrafluoroethylene, which has good sealing performance, corrosion resistance, acid and alkali resistance.

4. The kettle lid and the part above the kettle lid can be lifted and lowered electrically, and the kettle body can be rotated 150° to the left by the hand wheel, which is convenient for cleaning and manual rotation.

5. Glass + PTFE discharge valve, discharge on the side without liquid accumulation, and recover the solution very quickly.

6. Buffering device: After the inlet and outlet of the jacket are connected to the stainless steel hose, fixed to the bracket, and then connected to the external circulation pipe to reduce the pressure of the inlet and outlet liquid, it can also avoid the connection between the glass interlayer circulation port and the circulation pipe of damage.

7. Low-speed booster motor, frequency conversion speed regulation, fine-tuning through the knob, double-display speed control box can digitally display the speed and the temperature of the material in the kettle, stable performance, clear display control and data plane, easy to operate.

8. The stirring system adopts ceramic bearings and mechanical seals to prevent the stirring rod from being worn and chipped. It is resistant to high temperature, wear and tear, and has good sealing effect.

9. Adopt PT100 temperature sensor, 304 stainless steel, transparent PTFE tube, double anti-corrosion.

10. The vacuum pressure gauge shows the real-time vacuum, and the pointer shows it.

11. Crescent-shaped stirring paddle, 304 stainless steel + PTFE stirring blade; the stirring rod is made of 304 stainless steel, covered with PTFE tube, with high strength and strong corrosion resistance.

12. There is a Fo ma universal wheel with brakes at the bottom of the machine, which can be moved as a whole and is easy to operate.

13. Stirring and lifting fuse protection performance is high.

14. The motor is explosion-proof, the aluminum shell of the variable frequency speed regulator is explosion-proof, and the cable is through the explosion-proof tube.

SPECIFICATIONS

Model

LGR-EX5S

LGR-EX10S

LGR-EX20S

LGR-EX100S

Kettle capacity

5L

10L

20L

100L

Voltage frequency

220V/50Hz

220V/50Hz

220V/50Hz

220V/50Hz

Stirring motor power

90W

90W

120W

120W

Vacuum

0.098Mpa

0.098Mpa

0.098Mpa

0.098Mpa

stirring speed

0-450rpm/min

0-450rpm/min

0-450rpm/min

0-450rpm/min

Temperature measurement accuracy

±1

±1

±1

±1

Machine size (W×D×H)

700×850×(1820-2250 after rising) mm

700×850×(1820-2250 after rising) mm

750×920×(1920-2400 after rising) mm

900×1000×(2380-2950 after rising) mm

Machine net weight

175kg

185kg

190kg

190kg
