Small Closed Spray Dryer For Laboratory
Small Closed Spray Dryer For Laboratory

Small Closed Spray Dryer For Laboratory

The device is especially aimed at organic solvents, and uses the inert gas medium formed by circulating nitrogen to replace the usual air medium for spray drying. In addition to recovering products, organic solvents can also be recovered. This set of closed circulation spray system is specially designed for organic solvents with low flash point or slightly toxic characteristics, flammable and explosive characteristics.
  • ModelLBL-D1
  • BrandLABOAO
  • PortAny port in China
  • PackagePlywood case package
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat

Download

DESCRIPTION

The device is especially aimed at organic solvents, and uses the inert gas medium formed by circulating nitrogen to replace the usual air medium for spray drying. In addition to recovering products, organic solvents can also be recovered. This set of closed circulation spray system is specially designed for organic solvents with low flash point or slightly toxic characteristics, flammable and explosive characteristics.


FEATURES

1. Can prevent oxidation, avoid danger and improve quality.

2. Easy to achieve aseptic and dust-free.

3. The solvent in the feed liquid can be recovered.

4. Improve the preservation of aromatic components.

5. It can dry or cool and granulate combustible material liquid.

6. It can dry the material liquid with high heat sensitivity.

7. It can achieve low pollution and no pollution.

8. The deodorizing device can be omitted.

9. It can be dried at a low temperature below 100°C.

10. Using an innovative atomization system, this system uses a hard contact mechanical structure without any gaskets and no leakage. Different from ordinary electric centrifugal nozzles, the superheated corrosive steam contacts the wires of the electric nozzle for a long time under positive pressure, thereby corroding the wires, causing the plastic skin on the surface of the wires to corrode, soften and fall off, thus forming a short circuit. It can achieve 1-8 microns A range of ultrafine powders, suitable for the preparation of battery materials.


SPECIFICATIONS

Model

LBL-D1

Ethanol evaporation

0.8Kg/h

Minimum feed amount

50ml

atomization structure

Atomization system   (NZY1VER2018-1A)

Electronic control system

Special for closed loop   atomization system (BLD-ES-VER2018-1A)

Inlet air temperature   (Celsius)

140

Drying chamber diameter (mm)

300

Drying tower height (mm)

600

Explosion-proof disk diameter   (mm)

65

heater capacity

2Kw

Induced fan [power (kw), air   volume (m³/h)]

[1.5, 250]

Compressor [power (kw), air   volume (L / min)]

[0.58, 108]

Chiller

50-60Hz (built-in cryogenic   cooling circulation pump)

Electronic control main   accessories standard (including PLC, analog module, touch screen) (optional)

Wecon control module   (standard)

Selection criteria for   electric control auxiliary accessories (including contactors, etc.)   (optional)

Chint (Standard)

Parts in contact with the   material (optional)

SUS304 (standard)

Exhaust gas reuse, saving   energy by more than 30% (optional)

Not assembled (standard)

Atomizing nozzle (optional,   diamond coating or not)

SUS304 (standard)

Equipment Warranty

1 year (standard, a certain   maintenance fee will be charged for the above)

Electricity (installed   capacity)

4Kw

Pulse bag filter

PTFE coating material,2pcs

Dimensions (mm) (L×W×H)   Reference

1400×1000×1600

Installation weight   (reference)

200Kg

Power supply

380V/-3 (Related voltages can be customized   according to different national standards)

Notes

1. Ethanol   evaporation is based on the inlet air temperature of 140°C; 2. If you need   equipment with larger evaporation capacity, please inquire online or call our   company
