10L single layer glass reactor

Single layer glass reactor is an equipment which is a collaboration of vacuum state, distillation, reflux, stirring, oil/water heating, heating mantle. It can do all kinds of biochemical reactions and synthesis reactions at a constant temperature condition. It is also a colsed system on the whole.
  • BrandLABOAO
  • ModelLGR-10F
  • PortAny port in China
  • PackagePlywood case package
Payment More
We also supports L/C、D/A、D/P、Western Union、MoneyGram、Discover payments for offline orders.

DESCRIPTION

Single glass reactor inner placed reaction solvent which can be stirred, single layer glass reaction kettle is heated by computer control oil bath or electric heating. At the same time, it can be worked at atmospheric pressure or vacuum state, to control the reaction solution reflux and distillation, it is the ideal equipment for modern synthesis chemical, biological pharmaceuticals and making new materials, used for preparation experiment and production equipment.

FATURES

1. Frequency control, AC induction motor, speed digital display constant, brushless, no spark, safe and stable, it can work continuously;

2. Supporting glass using GG3.3 high boron silicon material production, has a good chemical, physical properties; big bottle design, hand out cleaning;

3. PTFE (Ceramic) mechanical component sealing, proprietary technology, it can get the best vacuum degree in the market among the similar products;

4. Overall stainless steel frame structure (foot connecting parts like Tee and four-way valve are all stainless steel), compact and solid, stable and reliable without shaking when mixing;

5. Casters with brake fixed, it is convenient and reliable for mobile use;

6. The PTFE discharge valve without dead corner, solid material/liquid material can be easily released from the bottom;

7. Computer controlled thermostatic oil bath, the intelligent PID control, temperature control is accurate and convenient;

8. Integral structure is scientific design and beautiful appearance, convenient for operation;

9. Explosion-proof series available.

( We can add the cooling coil and an anti-explosion device according to user's needs).

SPECIFICATIONS

Basic specification

Name

Single layer glass reactor

Model

LGR-10F

Volume

10L

Glass material

GG-17

pot shell material

Spraying antiseptic shell

Pot shell size(mm)

540*440*860

Inner port material

Stainless steel

Inner port size(mm)

350*220

Moving mode

Brake type universal corner wheel

Shape of reactor body

Ball type

Port No. of reactor cover

7

Distance between discharge to   floor

450mm

Temperature range

-80 to 250 degree

Vacuum

0.098Mpa

Stirring speed

0-450rpm

Stir rod diameter

15mm

Stir motor

90W1/3

Heating power

3KW

Overall size (mm*mm*mm)

600*440*1900

Package size (mm*mm*mm)

1100*620*790

Gross weightKG

63

Configuration list

Motor

Low speed booster motor, speed   ratio 3: 1

Speed display mode

LCD digital display

Temperature display

digital display

Seal

70 flange stir port

Condenser

100*600mm

Reflux (distillation) device

Return bend with feeding switch,   50# ball mill port

Drop adding device

1L /34 standard

Pressure release device

standard 34# pressure release   valve

Temperature tube

standard 24#

Solid adding (cleaning) port

120 flange port with PTFE cover

Discharge

glass discharge valve, 80 flange port

Vacuum display mode

Vacuum gauge

Mixing connection

universal joint link
