20L Short Path Molecular Distillation With Double Collection

20L double collection short path distillation is one of our short path distillation series products, which can be operated under extremely high vacuum, it is especially suitable for the separation of high boiling point and heat sensitive substances.
  • ModelLSD-20L
  • BrandLABOAO
  • PortAny port in China
  • PackagePlywood case package
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat

DESCRIPTION

Short path distillation is a new distillation technique, which is usually carried out under reduced pressure.This technique is typically used for compounds that are unstable or have small amounts of purification at high temperatures.The advantage is that the heating temperature (under reduced pressure) can be much lower than the boiling point of the liquid at standard pressure, and the distillate only needs to travel a short distance before condensing.The shorter path ensures that very little compound is lost on the side of the device.

FEATURES

1. The separation operation can be realized at the temperature of the boiling point of the material, as long as the pressure of the system is lower than the saturated vapor pressure of the light component of the material and the distance between the heating surface and the condensation surface is less than or equal to the molecular mean free path of the light component. Can achieve the purpose of separation.

2. There is no bubbling or boiling phenomenon, which is conducive to maintaining a high vacuum degree in the whole system.

SPECIFICATIONS

LSD-20L

Part Description

Quantity

Round Bottom Flask, 20L, 3-neck

1

Short Path Distillation Head,Vacuum Jacket

2

Distillation Cow Receiver,1-to-3,24/40

2

24/40 round bottom flask 1000ml

6

Heating mantle (room temperature - 300 degrees)

1

Keck Clamp, stainless steel

3

Keck Clamp, plastic

8

Stainless Steel elevator-platform

5

Cork Ring Stand for Flask

3

Clamp Holder

1

Lab support Stand

1

Cold Trap

1

1L cold trap collection bottle

1
