1064nm High Sensitivity Portable Refrigerated Raman Spectrometer

1064nm High Sensitivity Portable Refrigerated Raman Spectrometer

2024 September Sale ends in

LATR3000-1064 is a portable Raman spectrometer with an excitation wavelength of 1064nm, and is a member of the well-known LATR3000 series in the field of scientific research. LATR3000-1064 is equipped with a laser with an excitation wavelength of 1064nm and a Raman filter set with a high extinction ratio, and uses a high-sensitivity InGaAs array detector, ultra-low temperature TE refrigeration, so as to obtain a better signal-to-noise ratio and more High dynamic range.

ModelLATR3000-1064
BrandLABOAO
PortAny port in China
PackagePlywood case package

Request Quotation Chat Now

WhatsApp Chat
WeChat Chat

Download

DESCRIPTION

Due to the low fluorescence characteristics of 1064nm, LATR3000 avoids fluorescence interference and is suitable for detecting a large number of high fluorescence samples, such as dyes, printing inks, petroleum, biological samples, etc. The spectrum of ATR3000-1064 covers 200~260-1, and the spectral resolution is 13 cm-1. The design features of small size, light weight and low power consumption enable ATR3000-1064 to provide laboratory-level Raman testing anywhere. Very suitable for laboratory scientific research. Superior reliability and repeatability (temperature, long time) make the detection results accurate and reliable, and the excellent low stray light conditions make the spectrometer have a wide range of applications, especially suitable for dark samples, colored samples, fluorescent samples, biological samples, bacteria, fuels, Petroleum samples, vegetable oil, pharmaceuticals, explosives and other samples.

Applications:

Biological science

Pharmaceutical engineering

Forensic analysis

Agriculture and food safety

Gemstone

Environmental science

FEATURES

1. Low temperature refrigerated linear InGaAs CCD sensor;

2. Ultra-low temperature refrigeration: -20℃

3. Ultra-low noise circuit;

4. Powerful embedded software;

5. Eliminate fluorescent background;

6. Peak search and display;

7. Android 6.0 operating system;

8. 11.6-inch capacitive touch screen, support multi-touch;

9. HD touch screen, 1920X1080;

10. USB 2.0;

11. Friendly man-machine interface;

12. Battery life> 5h;

13. Support LAN remote control;

14. IP67 waterproof and dustproof;

SPECIFICATIONS

Model		LATR3000-1064
Interface		USB
Integration Time		1ms-30m
Operating Temperature		-10℃- 40℃
Operating Humidity		90%
Dimension		120um
Weight		5kg
Raman Spectrometer Detector
Detector Model		Hamamatsu S10420+TEC
Cooled Down To		-5℃
Dynamic Range		50000:1
Pixel Size		14×14pixels
Raman Spectrometer Laser Parameters
Excitation Wavelength		785nm
Laser Output		600mW; 500mW at probe
Raman Spectrometer Optical Parameters
Spectral Range		250-2700; 200-3500; 200-4200.
Resolution		6(250-2700); 8(200-3500); 10(200-4200).
Library	Item	Spectral Library	Application
	LATR3000-1064	Self-built database	Research field
	LATR3000DH-1064	Can detect drugs, chemicals, flammable and explosive, precursor drugs, pesticides	Public security, customs, subways, courts, prisons, public places, etc.
	LATR3000PH-1064	Raw material inspection	Pharmaceutical factory
	LATR3000GM-1064	Diamonds, jade, agate, emeralds, gems, minerals, etc.	Jewelry appraisal
	LATR3000CH-1064	Various chemicals, toxic and hazardous substances, etc.	Chemical composition identification

APPLICATION

Materials Analysis
Pharmaceutical and Biomedical Research
Forensic Identification
Environmental Monitoring and Analysis
Narcotics Hazardous Chemical Detection
Agricultural Monitoring and Food Safety
Gem Identification and Mineral Screening
Art and Archaeology

WHY CHOOSE US

Factory direct sales with competitive price.
Premium quality with CE & ISO certification.
Strong product OEM & ODM customization capability.
Promise production & on-time delivery.
Perfect after-sales service, free product accessories.
15 years of experience in R&D and production of raman spectrometer machine.

OUR FACTORY

We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.

PACKAGING & SHIPPING

Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.

CUSTOMER CASES

Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe LABOAO, we grow together!
