Portable Mini Raman Spectrometer

2024 September Sale ends in

LATR2500 is a brand new, optimized design, high-sensitivity portable Raman spectrometer with breakthrough features. It has the characteristics of ultra-small, ultra-light, high resolution, high sensitivity, and high reliability.

ModelLATR2500 Series
BrandLABOAO
PortAny port in China
PackagePlywood case package

Request Quotation Chat Now

WhatsApp Chat
WeChat Chat

Download

DESCRIPTION

LATR2500 adopts the latest full free space optical path technology, which increases the Raman signal collection efficiency by nearly 4 times, thus increasing the sensitivity by 4 times.The LATR2500 Raman spectrometer is very suitable for laboratory scientific research. It is small in size, highly reliable, can be measured easily, and the test results are accurate and reliable. The excellent low stray light design of the ATR2500 makes it easy to use. The multifunctional software shipped with the ATR2500 has been rigorously tested by hundreds of scientists around the world and collected their improvement opinions. It has been updated in nearly a hundred versions. Its functions are very complete and stable, and it is very suitable for the development of Raman research work.

FEATURES

1. Full free space design, super high sensitivity;

2. Ultra-high sensitivity detector;

3. Ultra-low noise circuit;

4. Ultra-light, ultra-small, ultra reliable;

5. Powerful spectral analysis software;

6. Eliminate fluorescent background;

7. Peak search and display;

8. USB 2.0;

9. Friendly man-machine interface.

SPECIFICATIONS

Model	LATR2500 Series
Integration time	4ms - 120s
Voltage	DC 5V±5%
Work temperature	-10~45℃
Work humidity	< 95%
Spectral reliability	σ/μ < 0.5% (COT 8 hours)
Temperature reliability	Spectral shift ≤ 1 cm (10-40℃)
Spectral intensity	<±5%（in 5 ~ 40℃）
Spectral range	250-2700 cm-1	/	200-4000 cm-1
Resolution	4~6 cm-1	/	7~10 cm-1
SNR	>1300:1 (918 cm of Acetonitrile，4sIntergation, 130mW)
Spectral range	200-1100 nm
Effective pixels	2048 pixels
Dynamic range	50000:1
Center wavelength	785±0.5nm
Half width	0.08nm
Maximum output power	≥300 mW，the actual output power software can be set
Minimum power output adjustment	1mW
Power stability	σ/μ <±0.2%
Rayleigh Scatter Resistance	6 mm
Operating Distance(OD)	OD>8
NA	0.3
Aperture	7mm
Interface	USB 2.0
Dimension(LWH)	Without probe: 119.2×89×35 mm
	With probe: 139×89×35 mm
Weight	390 g

APPLICATION

Materials Analysis
Pharmaceutical and Biomedical Research
Forensic Identification
Environmental Monitoring and Analysis
Narcotics Hazardous Chemical Detection
Agricultural Monitoring and Food Safety
Gem Identification and Mineral Screening
Art and Archaeology
