Large Capacity Industrial Drying Oven

Industrial ovens are used for drying, baking, wax melting, and sterilization in industrial and mining enterprises, laboratories, and scientific research units.

Model LGF series
BrandLABOAO
PortAny port in China
PackagePlywood case package

Request Quotation Chat Now

WhatsApp Chat
WeChat Chat

Download

DESCRIPTION

The industrial oven uses the connection between the digital display instrument and the temperature sensor to control the temperature of the working room, and uses the hot air circulation to dry the material. The hot air circulation system is divided into horizontal air supply and vertical air supply, all of which have been professionally designed. The motor runs to drive the air supply wind wheel, so that the blown air is blown on the electric heating tube to form hot air, and the hot air is sent from the air duct to the working room of the industrial oven, and the used hot air is sucked into the air duct again to become the wind source for recirculation heating, greatly improving temperature uniformity. If the box door is opened and closed during use, the air circulation system can be used to quickly restore the temperature value of the operating state.

FEATURES

1. Large capacity, high efficiency, safety and wide range.

2. Independently developed air duct design, fast drying, uniformity meets the national standard.

3. PID temperature controller, microcomputer temperature control

4. Special function keys for temperature setting.

5. Auxiliary menu to realize overheating alarm, deviation correction and menu lock.

SPECIFICATIONS

Model	LGF-4AB	LGF-5AB	LGF-6AB	LGF-7AB
Method	Side duct forced air supply	Patented three-duct forced convection
Operating temperature range	RT+10-250°C
Temperature resolution	0.1°C
Temperature fluctuation	±1°C
Temperature distribution accuracy	±2.5°C
Inner material	Stainless steel plate
Outer shell	Cold-rolled steel plate, with chemical-resistant coating on the surface
Thermal insulation material	Aluminum silicate fiber
Heater	Stainless steel heating tube
Rated power	6kw	12kw	24kw	24kw
Exhaust port	Inner diameter 50mm*2, adjustable exhaust
Temperature control mode	PID
Temperature setting method	Touch four buttons to set
Temperature representation mode	Measured temperature display： 4-digit upper digit display; set temperature display: 4-digit lower digit display
Timer	0-9999 minutes (with timing waiting function)
Operation function	Fixed value operation, timing operation, automatic stop
Program mode	Optional
Additional functions	Deviation correction, menu key lock, power failure compensation, power failure memory
Sensor	Pt100
Safety device	Over-rise alarm, independent temperature limit, overload protection, phase loss protection
Inner size (mm)	100010001000	120012001200	160012001600	160016001600
External dimensions (mm)	159312921300	173617641500	219221501960	219025101960
Packing dimension (mm)	177314341525	192219541695	NO	NO
Inner volume	1000L	1700L	3100L	4100L
Shelves load	50 kg		Walk-in type (with optional trolley, shelves)
Number of layers	Standard is 2layers 6 layers optional	Standard is 2layers 8 layers optional	Walk-in type (with optional trolley, shelves)
Shelve spacing	140 mm
Power supply rated current (50/60Hz)	AC380/9.1 A	AC380/18.2A	AC380/36.4A	AC380/36.4A
Accessories	Partition 2 pieces		No
Optional	Partition, RS485 interface, printer, recorder, remote control, program temperature controller, U disk data storage, Mobile APP (remote control)

APPLICATION

Research and Development
Biotechnology Pharmaceutical
Food and Beverage Processing
Industrial Applications
Environmental Testing
Textile and Apparel Industry

WHY CHOOSE US

Factory direct sales with competitive price.
Premium quality with CE & ISO certification.
Strong product OEM & ODM customization capability.
Promise production & on-time delivery.
Perfect after-sales service, free product accessories.
15 years of experience in R&D and production of electric drying oven machine.

OUR FACTORY

We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.

PACKAGING & SHIPPING

Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.

CUSTOMER CASES

Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe LABOAO, we grow together!
