10kg Centrifugal Spray Dryer Machine
10kg Centrifugal Spray Dryer Machine

10kg Centrifugal Spray Dryer Machine

Spray drying is a method of producing a dry powder from a liquid or slurry by rapidly drying with a hot gas. This is the preferred method of drying of many thermally-sensitive materials such as foods and pharmaceuticals. A consistent particle size distribution is a reason for spray drying some industrial products such as catalysts. Air is the heated drying medium.
  • ModelLPG-10
  • BrandLABOAO
  • PortAny port in China
  • PackagePlywood case package
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat



LPG-10 spray dryer is a drying equipment suitable for the liquid material with low temperature and high viscosity, which has been improved many times on the basis of domestic and foreign spray dryers. The working principle is: cold air is filtered through the filter, then enters the heater, is heated to a certain temperature, and then enters the air distributor at the top of the spray tower, and the hot air spirally flows to the bottom of the tower. The liquid is pumped to the centrifugal atomizer at the top of the tower body, and the liquid is torn into extremely small mist droplets. The liquid droplets and the hot air are in parallel contact, and the heat exchange is fully performed. The water content is rapidly vaporized and evaporated, and dried in a very short time as a finished product. The finished product is separated by a cyclone and discharged, and the exhaust steam is discharged by an induced draft fan.


Chemicals: polyaluminum chloride, disperse dyes, reactive dyes, organic catalysts, white carbon black, washing powder, zinc sulfate, silicon dioxide, sodium metasilicate, potassium fluoride, calcium carbonate, potassium sulfate, inorganic catalysts, each Waste liquid, etc.

Food: amino acids, vitamins, egg powder, bone meal, seasonings, protein, milk powder, pig blood powder, soy sauce powder, coffee, tea, glucose, potassium sorbate, pectin, flavors and fragrances, vegetable juice, yeast, starch, etc.

Ceramics: alumina, zirconia, magnesia, titania, magnesium titanate, clay, china clay, various ferrites and metal oxides.



1. The spray drying speed is fast. After the liquid is atomized, the surface is greatly increased. During the contact with hot air, 95%-98% of the water can be evaporated in an instant, and the drying time takes only a few seconds, which is especially suitable for heat sensitive materials. Dry.

2. The product has good uniformity, fluidity and solubility. The higher the purity of the product, the better the quality.

3. The spray dryer production process is simplified, and the operation control is controlled. For liquids with a moisture content of 40-60% (up to 90% of special materials), the product can be dried into a powdered product at one time. After drying, no pulverization and screening are required, the production process is reduced, and the purity of the product is improved. The particle size, bulk density and moisture of the product can be adjusted within a certain range by changing the operating conditions, and the control and management are very convenient.





Maximum   water evaporator


Inlet air   temperature

160 ° C -200   ° C

Outlet air   temperature

80 ± 5 ° C

Control   system

PLC control

Particle   size


Heating   source

Electric   heating

Heating   power



  1. Factory direct sales with competitive price.
  2. Premium quality with CE & ISO certification.
  3. Strong product OEM & ODM customization capability.
  4. Promise production & on-time delivery.
  5. Perfect after-sales service, free product accessories.
  6. 15 years of experience in R&D and production of centrifugal spray dryer machine.
laboao certification


We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.

laboao factory


Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.

laboao packaging and shipping


Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe LABOAO, we grow together!

laboao customer cases


Authenticity GuaranteedWe assure you purchase our products are 100% certified products.
24*7Hours ServiceProvide 7*24 hours service telephone & support email to help you solve problems quickly.
Technical SupportProvide equipment installation, adjustment, operation training, etc.
1 Year WarrantyFree maintenance and accessories within warranty period(not caused by human factors).
