DESCRIPTION
This MT series laboratory water purification systems are suitable for all kinds of physical and chemical detection, biochemical analysis, blood test, micro analysis, washing special, HPLC, IC, GC, analysis experiments.
This MT series laboratory water purification systems are suitable for all kinds of physical and chemical detection, biochemical analysis, blood test, micro analysis, washing special, HPLC, IC, GC, analysis experiments.
1. Built-in filter 10 micron 316L stainless steel precision mesh filter to remove fine impurities instead of PP cotton filter; manual drain valve, automatic cleaning at any time, soft scraping design for more thorough drainage,transparent shell filtering effect is intuitively visible; filter element is free to save money and effort.
2. The long-acting KDF device adopts the original imported filter material in the United States. It removes residual chlorine, heavy metals, and inhibits the growth of fungi at the front end of the purified water. It has a long service life better protects the post-purification system, and extends the use time of the ultra-purification column.
3. The water quality of the innovative built-in transparent pressure bucket is transparent, and the innovative replaceable liner water storage bag uses nano antibacterial technology to design the material to resist special ultraviolet rays reduce the odor of microorganisms and bacteria, and reduce organic chemicals such as nitrite. Prevent secondary water pollution in the pressure tank.
4. The case adopts plastic spraying process and side-opening door design. The filtering system adopts 11-inch U-shaped Korean quick-inserted filter column for easier replacement and maintenance, and has the function of upgrading water quality and quantity.
5. Backlight LCD display, dual waterway online monitoring, which can simultaneously display RO conductivity value, UP resistivity value and equipment operating status indication.
6. Menu-type operation, which can modify and set a number of measurement parameters; has a number of operating status displays and indicator lights to promptly reflect the operating status of the equipment, high-pressure shut down low-pressure alarm, water full shutdown, etc.
7. RO water Ultra-pure water quality alarm warning prompt Automatic replacement of the filter element, you can set the water with drawal time; touch the button to take water, RO UP water light indicator automatically prompts.
8. Equipped with a portable test pen,which can test TDS content, conductance and water temperature anytime, anywhere
9. Pipeline adopts a quick-plug interface, the pipe joint passes NSF certification, dual-wavelength UV lamps, effective sterilizes and reduces TOC, and the original imported 5000D ultrafiltration module effectively removes endotoxin.
Model | Standard; Eliminating endotoxin; Low TOC; Synthesizing | |||
MT-10 | MT-F10 | MT-V10 | MT-VF10 | |
MT-20 | MT-F20 | MT-V20 | MT-VF20 | |
MT-30 | MT-F30 | MT-V30 | MT-VF30 | |
Process | PRE+KDF+PP+AC+RO+UP+TF | PRE+KDF+PP+AC+RO+UP+UF+TF | PRE+KDF+PP+AC+RO+UP+UV+TF | PRE+KDF+PP+AC+RO+UP+UV+UF+TF |
Output(25℃) | 10L/H, 20L/H, 30L/H | |||
Flow rate | Up to 2 liters/minute(with pressure tank) | |||
Pure water outlet | 2: reverse osmosls water, ultra-pure water | |||
Ultra pure water quality | ||||
Resistivity(25℃) | 18.2MΩ.cm | |||
TOC | <10ppb | <10ppb | <3ppb | <3ppb |
Bacteria | <0.1cfu/ml | |||
Particle(>0.22μm) | <1/ml | |||
Endotoxin | N/A | <0.001Eu/ml | N/A | <0.001Eu/ml |
RO water quality | ||||
Ion rejection rate | 95%-99%(new RO membrane) | |||
Particles and bacteria rejection rate | >99% | |||
Feed water requirements | Tap water, temperature: 5-45℃, pressure: 0.15-0.4Mpa | |||
Dimension and weight | L*W*H: 47*45*55cm/Weight: about 30KG | |||
Electrical requirements | AC110-240V, 50/60Hz | |||
Power | 48-240W | |||
Standard configuration | Machine(including 1 set of purification column)+terminal filter+ accessories package |
