The LPCR-H series is a portable isothermal amplification fluorescence detector. This product adopts 4-channel 8-hole module design. It adopts American MARLOW customized Peltier module, high-sensitivity photodetector and side scanning technology to ensure superior performance and stable detection results.
● Small size, light weight, easy to carry;
● Using side scanning technology, the detection distance is short, and the fluorescence acquisition signal is stable;
● Dark box type reaction tank to avoid background noise;
● Use the same collection optical path to improve repeatability;
● Using LED light source, energy saving and environmental protection, long service life, maintenance-free;
● Constant current control circuit, smooth power output, prolong Peltier life and improve temperature control accuracy;
● With over-current, over-temperature, power-down data self-recovery and other protection functions to ensure the safe operation of the experiment;
● Front and rear air duct design, can be placed side by side, saving laboratory space;
● Support lithium battery power supply, especially suitable for quick inspection and field inspection.
Model | LPCR- H8801 | LPCR- H8802 | LPCR- H8804 |
Capacity | 8×0.2ml | ||
Applicable consumables | 0.2ml thin-walled transparent single tube, 0.2ml thin-walled transparent eight tubes | ||
Reaction system | 15-100μl | ||
Temperature Range | 0~100℃ (resolution: 0.1°C) | ||
Maximum heating and cooling rate | 8℃/s | ||
Temperature control technology | American MARLOW semiconductor refrigerator, more than 1,000,000 cycles | ||
Uniformity | ±0.25℃ | ||
Accuracy | ±0.1℃ | ||
Temperature Control | Block\Tube | ||
Hot Lid Temperature | 30~110℃ (adjustable, default 105℃) | ||
Fluorescence excitation wavelength | F1:470nm | F1:470nm F2:523nm | F1:470nm F3:571nm F2:523nm F4:628nm |
Fluorescence detection wavelength | F1:525nm | F1:525nm F2:571nm | F1:525nm F3:612nm F2:571nm F4:692nm |
Applicable fluorescent dyes | F1: FAM/SYBR Green I | F1: FAM/SYBR Green I F2: HEX/VIC/JOE/TET | F1: FAM/SYBR Green I F2: HEX/VIC/JOE/TET F3: ROX F4: CY5 |
Excitation light source | High brightness LED, long service life, no maintenance | ||
Detector | High sensitivity photoelectric sensor | ||
Dynamic range | 1-1010 Copies | ||
Detection sensitivity | Can detect single copy genes | ||
Software analysis function | Quantitative/qualitative | ||
Data export format | excel, csv, txt | ||
USB thermal printer optional | |||
Interface | WIFI/USB2.0 | ||
Dimension | 195×165×140mm (L × W × H) | ||
Weight | 3KG | ||
Operating Voltage | 220VAC, 50Hz | ||
Power | DC15V 255W | ||
