With refrigeration stackable constant temperature oscillator, it can be used alone or three stacked on top of each other, and only one floor of the stacked constant temperature oscillator is needed. Three-axis eccentric balance movement, stable and reliable, long service life. The speed control system has a speed terminal feedback system to keep the machine oscillating with high precision.
Model | LIS-6C | LIS-6C5 |
product name | 401L, Touch Screen, with Co2 | 401L, Touch Screen, With Co2, Amplitude 50 |
Shaker size | 900*560mm | |
Number of flask clamps / stickers | FlaskClip:50ml*135/100ml*60/150ml*60/200ml*60/250ml*60/500ml*34/1000ml*22/2000ml*15/3000ml*12/5000ml (Thomson)*6 Adhesive pad:50ml*187/100ml*112/150ml*104/200ml*84/250ml*77/500ml*40/1000ml*28/2000ml*15/3000ml*15/5000ml (Thomson)*6 | |
capacity | 401L | |
Maximum load | 20kg | |
Temperature control range | Below room temperature 18 ℃ -60 ℃ (minimum 4 ℃) | |
Temperature control accuracy | +/-0.1℃ | |
Temperature uniformity | +/- 0.5 ℃ (@37 ℃) | |
Rotation speed | 0(stop),30-300rpm | |
Speed accuracy | +/-1 rpm | |
amplitude | 26mm | 50mm |
CO2 sensor | IR (infrared) | |
CO2 concentration control range | 0-20% | |
CO2 concentration control accuracy | +/-0.1% | |
Temperature recovery time after opening the door for 30s | ≤6 min (@37℃) | |
CO2 concentration recovery time after 30s of door opening and restart | ≤6 min (@5%) | |
Humidity type | Natural humidification | |
Humidity | 95% | |
Programmable number of segments | 12 segments | |
illumination | Two-way lighting | |
Sterilize | UV sterilization | |
Door opening method | Down open | |
Set parameter protection | password protection | |
Curve display type | Humidity curve, speed curve, CO2 concentration curve, humidity curve | |
Display method | Capacitive, 10-inch color touch screen | |
Timing range | 0-999 hours and 59 minutes | |
USB flash drive export data | YES | |
Days of operation parameters can be checked on the screen | Within seven days | |
Run data storage cycle | More than 912 days | |
Operation data storage interval | 1 minute | |
Data storage content | Running time, temperature parameters, speed parameters, humidity parameters, running status | |
Automatic defrost | YES | |
Turn off screen display automatically | YES | |
Auto lock screen | YES | |
The third layer shake plate height | 1496mm | |
Rocker with track | YES | |
Noise level | ≤55dB(When cooling) | |
Washable | YES | |
Interface language | English | |
Automatic call recovery | YES | |
Heating power | ≤850W | |
Cooling power | 70-180W | |
Power | ≤1000W | |
Power supply | AC 220V+/-22V, 50/60HZ | |
Active humidification (optional) | 10% -95% above ambient humidity optional | |
WIFI mobile monitoring (optional) | Optional | |
Computer monitoring (optional) | Optional | |
Shading plate (optional) | Optional | |
Net weight | 295kg | |
Inner cavity working height | 330mm | |
Dimensions | 1400*886*(600+80 Foot height) mm | |
