Experimental Spray Freeze Dryer

LFSD-1 Experimental spray freeze dryer is an original product carefully developed by our company combining spray drying technology and vacuum freeze drying technology. Since the product came out, we have been steadily improving in function, performance and ease of use, spray freeze drying The processing capacity of each batch of the machine is 2000ML/time, and the drying time of some materials does not exceed 5 hours. The processing capacity of each batch of the customized spray freeze dryer reaches 5000ML/time and 10L/time. A series of spray freeze-dried products tried in the pilot test.
  • ModelLFSD-1
  • BrandLABOAO
  • PortAny port in China
  • PackagePlywood case package
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat



LFSD-1 Laboratory refrigerated spray dryer is suitable for low temperature drying of heat-sensitive, viscous, active materials and materials with high sugar content, such as natural product extracts of Chinese herbal medicine, dairy products, biological preparations, enzyme preparations, fruit juice, polymer materials Wait.



1. LFSD-1 The laboratory spray freeze dryer organically combines spray drying and vacuum freeze drying. The drying time required is extremely short, and the drying time of some materials does not exceed 5 hours (2000ML/time), which greatly shortens the traditional vacuum drying time. Freeze-drying time, and the dried material is a powdery solid, and the original biological and chemical properties of the spray-freeze-dried items are basically unchanged, and it is easy to store for a long time;

2. LFSD-1 The laboratory spray freeze dryer adopts an air-cooled condensing type fully enclosed compressor refrigeration system, which has rapid refrigeration, low freezer temperature, strong water absorption capacity, and digital display of temperature and vacuum degree, which is accurate and intuitive;

3. Freeze spray-dried items are naturally heated and sublimated by air to maintain the safety of samples;

4. The main unit is equipped with a vacuum pump power plug, no need to connect another power supply, and it is easy to use;

5. The vacuum connection adopts the international standard clamp, which is convenient and reliable;

6. Stable performance, easy operation and low noise;

7. LFSD-1 Laboratory spray freeze dryer compared to traditional freeze dryer: it can quickly freeze dry liquid materials that are easy to stick to walls and contain organic substances (juice, Chinese medicine extract, etc.), and the dried finished product is in a granular state, with good fluidity and granularity The particle size is adjustable within a certain range.





Drying Capacity

1500ml/Time, Each Drying Time Is Less Than 6   Hours (From Feeding To Discharging)

Spray Freezing Temperature


Cold Trap Temperature


Vacuum Pump Power


Vacuum Pressure


Spray Pressure

2-5Bar (Adjustable)

Compressed Air

4.2 m³ /h

Spray Head Type



Standard 0.7mm/(0.5/1.0/1.5/2.0mm Optional)

Body Material

Sus 304 Stainless Steel

Operating Mode

Automatic / Manual


Silica Gel

Vacuum Display



7-Inch Lcd Display With Usb Interface

Sample Safety

Vacuum Cryogenic Mode

Particle Size After Drying
