H-16 benchtop high speed centrifuge
- ModelH-16
- BrandLABOAO
- PortAny port in China
- PackagePlywood case package
- Max. speed16000rpm
- Max. RCF20600 g
- Capacity6×100ml
- RefrigeratedNO
FEATURES
1. Brushless DC motor in great torque, no carbon dust pollution, unnecessary to maintain, quick in speed up and down.
2. Automatically electric lid lock, super speed, over temperature protection and imbalance protection. The centrifuge body is made of high quality steel, safe and reliable.
3. Rotor is connected to spindle by specialized taper sleeve, loading simple and quick, no direction, safe and reliable.
4. Microprocessor control;
5. LCD display screen is optional, 10 programs stored in the memory, 10 speed rate for optional.
6. Three-stage vibration reduction, to reach the best centrifugal result.
SPECIFICATIONS
Max. speed | 16000r/min |
Max. RCF | 20600*g |
Speed accuracy | ±50r/min |
Time range | 0~99min |
capacity | 6*100ml |
Noise | ≦65dBA |
Rotor identification | Automatic identification |
Dimension | 515*370*320mm |
Packaged dimension | 730*430*425mm |
Weight | 42KG |
Packaged weight | 48KG |
Power | AC110/220V, 50-60HZ,10A |
Package | wooden box |
Optional rotors:
Rotor No. | Rotor type | Max . speed (r/min) | Capacity | Max. RCF |
NO30416 | Angle rotor | 15000 | 30×0.5ml | 18510 |
NO30402 | Angle rotor | 14000 | 40×0.5ml | 19970 |
NO30401 | Angle rotor | 16000 | 12×1.5/2ml | 16270 |
NO30403 | Angle rotor | 15000 | 24×1.5/2ml | 20600 |
NO30404 | Angle rotor | 13500 | 30×1.5/2ml | 19340 |
NO30444 | Angle rotor | 11000 | 48×1.5/2ml | 12840 |
NO30405 | Angle rotor | 15000 | 16×5ml | 19350 |
NO30406 | Angle rotor | 14000 | 12×7ml | 16370 |
NO30415 | Angle rotor | 14000 | 6×10ml | 16460 |
NO30408 | Angle rotor | 13000 | 12×10ml | 14510 |
NO30407 | Angle rotor | 10000 | 12×15ml | 11840 |
NO30639 | Angle rotor | 5000 | 24×15ml | 3080 |
NO30627 | Angle rotor | 5000 | 30×15ml | 3830 |
NO30409 | Angle rotor | 12000 | 8×20ml | 14510 |
NO30410 | Angle rotor | 12000 | 6×30ml | 14000 |
NO30411 | Angle rotor | 11000 | 6×50ml | 13480 |
NO30412 | Angle rotor | 12000 | 6×70ml | 10810 |
NO30413 | Angle rotor | 12000 | 4×100ml | 14850 |
NO30414 | Angle rotor | 8000 | 6×100ml | 7280 |
NO30437 | Angle rotor | 12000 | 24 capillary | 15800 |
NO30980 | Swing rotor | 13000 | 4×5ml | 14960 |
NO30676 | vertical rotor | 4000 | 2×3×48 hole | 2300 |
NO30935 | Plate rotor | 14000 | 16×5ml | 12660 |
